Camera Custom
Perfect Optics is a cutting-edge technology company specializing in the research and development of optical equipment and processes, as well as the design and manufacturing of high-precision optical components and systems. Our core business encompasses a wide range of products, including ultra-precision machining equipment (such as ion beam machining systems, robot machining systems, CNC polishing machines, and magnetorheological polishing machines), advanced coating equipment (ALD, IBS coating machines, etc.), precision components (ion sources, light control systems, magnetorheological fluids), ultra-precision manufacturing capabilities (for flat, spherical, aspheric, and freeform surfaces), and customized lenses and optical systems tailored to meet specific customer requirements.
Why Choose Us
Professional Team
Backed by a team of highly skilled and experienced professionals with decades of expertise in the optical field, we have mastered the entire process of manufacturing optical components with nanometer-level precision and even sub-nanometer accuracy.
Advanced Equipment
Our has lupho scan 420, lupho scan 600, zygo, 4d and other ultra-precision detection equipment, We will make every effort to achieve the required accuracy.
Our Service
With a strong commitment to technological excellence and top-notch customer service, we deliver premium optical solutions to clients across various industries.
Types of Camera Custom
We offer the following Product introduce:
High Magnification Camera
It is a high-precision optical element with many advantages. The magnification of 100 times allows users to observe the tiny defects or details on the measured object more clearly, thus improving the accuracy of product quality control. Secondly, the compound color difference technology can eliminate color deviation and ensure the authenticity and accuracy of the image.
Large Numerical Aperture Microscope
Large numerical aperture microscope is a high-end microscope, and its main parameters include resolution, numerical aperture, magnification and field of view. Compared with ordinary microscope, large numerical aperture microscope has higher resolution and larger numerical aperture, which can realize higher definition observation.
Manual Focusing Lens
Manual focusing lens is a kind of photographic lens whose definition can be adjusted manually. Its main parameters include focal length, aperture, focusing distance and focusing ring. Manual focusing lens can be used in various fields, including photography, film production, scientific experiments and so on.
Interferometer Standard Lens
It is the key component of interferometer, and its main parameters include focal length, field of view, wavelength range and so on. These parameters determine the resolution, detection sensitivity and measurement range of the interferometer. In the field of material detection, interferometer standard lens can be used to detect the thickness and refractive index of thin films. In surface topography analysis, interferometer standard lens can be used to evaluate surface quality and topography.
Ultraviolet Lithography Lens
It is one of the important equipments in integrated circuit manufacturing, and its main parameters include resolution, NA value, working wavelength, etc. The application fields are mainly integrated circuits, optical communication, medical treatment and other fields. In the future, with the increasing demand for high precision and high integration, the demand for ultraviolet lithography lenses will also expand. At the same time, with the continuous progress of science and technology, the lens manufacturing technology is also developing, which can produce higher-end ultraviolet engraving lenses, making its application range wider and having broad development prospects.
Product advantages
We offer the following Product introduce:
High Magnification Camera
One of the key advantages of a high magnification camera is that it enables you to get up close and personal with your subject, capturing even the smallest details. Whether you are photographing wildlife or capturing the intricate details of a complex machine, a high magnification camera will help you bring your subject to life in stunning detail.
Large Numerical Aperture Microscope
One of the most important features of a Large Numerical Aperture Microscope is its ability to capture high-resolution images. The numerical aperture of a microscope is a measure of its ability to capture light. A higher numerical aperture means that the microscope can capture finer details of an object. With a large numerical aperture microscope, researchers can observe biological processes and structures at a level of detail that was previously impossible.
Manual Focusing Lens
Another advantage of manual focusing lenses is that they tend to be lighter and more compact than their autofocus counterparts, making them ideal for travel photographers who want to pack light. These types of lenses can also be paired with manual film cameras for those who love the classic look and feel of film photography.
Interferometer Standard Lens
One major advantage of interferometer standard lenses is their high level of accuracy. These lenses can achieve sub-nanometer measurement resolution, providing extremely precise results that are unmatched by other measurement tools. This accuracy makes them a top choice for applications such as optical testing and semiconductor manufacturing.
Resolution In Common Use - Camera Custom
|
4:3 |
16:10 |
16:9 |
|
VGA(640x480) |
WVGA(800x480) |
QHD(960x540) |
|
SVGA(800x600) |
WSVGA(1024x600) |
720p(1280x720) |
|
XGA(1024x768) |
WXGA(1280x800) |
WXGA(1366x768) |
|
SXGA+(1400x1050) |
WXGA+(1440x900) |
1080p(1920x1080) |
|
UXGA(1600x1200) |
WSXGA+(1680x1050) |
|
|
QXGA(2048x1536) |
WUXGA(1920x1200) |
Custom And OEM Camera Modules
|
Camera Model |
Interface |
Color/Mono |
Sensor |
Sensor Size |
Pixel Size |
Resolution |
FPS |
Shutter |
Lens Mount |
|
IDX036 |
USB 2.0 |
Color |
OnSemi CMOS |
1/3" |
6.0um |
0.36 MP, 752x480 |
112 |
Global |
C/CS |
|
IDX036M |
USB 2.0 |
Mono |
OnSemi CMOS |
1/3" |
6.0um |
0.36 MP, 752x480 |
112 |
Global |
C/CS |
|
IDX120 |
USB 2.0 |
Color |
OnSemi CMOS |
1/3" |
3.750um |
1.2 MP, 1280x960 |
33 |
Global |
C/CS |
|
IDX120M |
USB 2.0 |
Mono |
OnSemi CMOS |
1/3" |
3.750um |
1.2 MP, 1280x960 |
33 |
Global |
C/CS |
|
IDX130M |
USB 2.0 |
Mono |
OnSemi CMOS |
1/2" |
5.2um |
1.3 MP, 1280x1024 |
29 |
Rolling |
C/CS |
|
IDX500 |
USB 2.0 |
Color |
OnSemi CMOS |
1/2.5" |
2.2um |
5.0 MP, 2592x1944 |
8 |
Rolling |
C/CS |
|
IDX500M |
USB 2.0 |
Mono |
OnSemi CMOS |
1/2.5" |
2.2um |
5.0 MP, 2592x1944 |
8 |
Rolling |
C/CS |
|
XW12 |
USB 2.0 |
Color |
OnSemi CMOS |
1/2.5" |
2.2um |
5.0 MP, 2592x1944 |
30 |
Rolling |
C/CS |
|
IDX1000 |
USB 2.0 |
Color |
OnSemi CMOS |
1/2.3" |
1.67um |
10 MP, 3664x2748 |
4 |
Rolling |
C/CS |
|
IDY130M |
USB 3.0 |
Monor |
OnSemi CMOS |
1/2.7" |
4.0um |
1.3 MP, 1280x1024 |
112 |
Global |
C/CS |
|
IDY213 |
USB 3.0 |
Color |
Sony CMOS |
1/1.2" |
5.86um |
2.3 MP, 1920X1200 |
40 |
Global |
C/CS |
|
IDY213M |
USB 3.0 |
Mono |
Sony CMOS |
1/1.2" |
5.86um |
2.3 MP, 1920X1200 |
40 |
Global |
C/CS |
|
IDY513 |
USB 3.0 |
Color |
Sony CMOS |
2/3" |
3.45um |
5 MP, 2448x2048 |
40 |
Global |
C/CS |
|
IDY513M |
USB 3.0 |
Monor |
Sony CMOS |
2/3" |
3.45um |
5 MP, 2448x2048 |
40 |
Global |
C/CS |
|
IDY603 |
USB 3.0 |
Color |
Sony CMOS |
1/1.8" |
2.4um |
6.3 MP, 3072x2048 |
40 |
Rolling |
C/CS |
|
IDY1203 |
USB 3.0 |
Color |
Sony CMOS |
1/1" |
3.1um |
12 MP, 4096x3072 |
15 |
Rolling |
C/CS |
|
IDY1203M |
USB 3.0 |
Mono |
Sony CMOS |
1/1" |
3.1um |
12 MP, 4096x3072 |
15 |
Rolling |
C/CS |
|
GMT036 |
GigE |
Color |
OnSemi CMOS |
1/3" |
6.0um |
0.36 MP, 752x480 |
112 |
Global |
C/CS |
|
GMT036M |
GigE |
Mono |
OnSemi CMOS |
1/3" |
6.0um |
0.36 MP, 752x480 |
112 |
Global |
C/CS |
|
GMT120 |
GigE |
Color |
OnSemi CMOS |
1/3" |
3.75um |
1.2 MP, 1280x960 |
33 |
Global |
C/CS |
|
GMT120M |
GigE |
Mono |
OnSemi CMOS |
1/3" |
3.75um |
1.2 MP, 1280x960 |
33 |
Global |
C/CS |
|
GMT200 |
GigE |
Color |
E2V CMOS |
1/1.8" |
4.5um |
2.0MP, 1600x1200 |
52 |
Global |
C/CS |
|
GMT200M |
GigE |
Mono |
E2V CMOS |
1/1.8" |
4.5um |
2.0MP, 1600x1200 |
52 |
Global |
C/CS |
|
GM133M |
GigE |
Mono |
OnSemi CMOS |
1/2" |
5.2um |
1.30MP, 1600x1200 |
30 |
Global |
C/CS |
|
GM503 |
GigE |
Color |
OnSemi CMOS |
1/2.5" |
2.2um |
5.0 MP, 2592x1944 |
14 |
Rolling |
C/CS |
|
GM503M |
GigE |
Mono |
OnSemi CMOS |
1/2.5" |
2.2um |
5.0 MP, 2592x1944 |
14 |
Rolling |
C/CS |
|
GM1003 |
GigE |
Color |
OnSemi CMOS |
1/2.3" |
1.67um |
10 MP, 3664x2748 |
8 |
Rolling |
C/CS |
Certificate
FAQ
We're well-known as one of the leading camera custom manufacturers and suppliers in China. If you're going to buy customized camera custom made in China, welcome to get pricelist from our factory. For price consultation, contact us.
